Smart radiator thermostat 868 MHz LoRaWAN Milesight WT101

The Milesight WT101 is a battery-powered smart radiator thermostat for wireless room-by-room heating control over LoRaWAN. This 868 MHz version fits hotels, apartments, offices, schools, hospitals, and other buildings where heating costs need to be reduced and room temperature needs to be controlled more precisely.

SKU:

incl. VAT105,91 excl. VAT89,00 plusShipping Costs

5 in stock

Related items

RAKwireless WisGate Edge Lite 2 Indoor LoRaWAN Gateway RAK7268V2 (EU868)

Indoor LoRaWAN Gateway 8-Channel – RAKwireless WisGate Edge Lite 2 RAK7268V2 (EU868, no LTE)

SKU: 715117 incl. VAT165,41 excl. VAT139,00 plusShipping Costs

4 in stock

TRA3015 smart radiator adaptor M30 X 1.5 Mm TRA3015

TRA3015 smart radiator adaptor M30 X 1.5 Mm TRA3015

incl. VAT11,78 excl. VAT9,90 plusShipping Costs

10 in stock

lps8 v2 dragino front

Dragino LPS8v2 with 4G LoRaWAN Gateway (EU868)

incl. VAT224,79 excl. VAT188,90 plusShipping Costs

3 in stock

Grand total: incl. VAT0,00 excl. VAT0,00 plusShipping Costs
Product Description Technical Details

The Milesight WT101 is built for radiator systems where temperature control should go beyond the rough adjustment of a standard thermostatic head. Instead of relying on fixed mechanical settings, it adjusts valve opening continuously based on the measured room temperature. This allows more precise heat output control, which can improve comfort and reduce unnecessary heating energy in real buildings.

The 868 MHz LoRaWAN version is especially relevant for retrofit projects in existing buildings where wireless deployment is preferred over running new control cabling. Typical use cases include hotels, residential buildings, office spaces, schools, hospitals, and other properties with many radiators across separate rooms. In these environments, room-by-room control is often much more useful than a one-size-fits-all heating approach.

A key strength of the WT101 is the combination of local valve regulation and wireless management. Heating schedules, open-window detection, freeze protection, and maximum valve opening control all help reduce wasted heat. This matters especially in buildings with changing occupancy. If a window is opened or a room is only used at certain times, heating behavior can be adjusted accordingly instead of continuing to heat unnecessarily.

The device also fits larger rollout projects well. NFC configuration, downlink control, and FUOTA support make it easier to manage many thermostats centrally. For hotels, apartment operators, or office building managers, this matters more than simple single-device functionality because it reduces on-site effort and ongoing maintenance overhead.

WT101 is the battery-powered version in the series. It runs on replaceable AA batteries and is designed for long service life. Its wide valve compatibility also makes it easier to retrofit across existing radiator installations without forcing a narrow hardware standard.

Model Milesight WT101
Product type Smart radiator thermostat
Version 868 MHz LoRaWAN, battery-powered
Wireless protocol LoRaWAN
Frequency EU868
Tx power 16 dBm at 868 MHz
Sensitivity -137 dBm
Mode OTAA/ABP Class A
Actuator Stepping motor
Default valve fitting M30 × 1.5 mm
Optional adapters RA, RAV, RAVL, Giacomini, M28 (Comap, Herz, TA)
Valve control features Automatic temperature control, valve opening control, heat plans, freeze protection, open-window detection, tamper alarm, effective stroke
Temperature sensor NTC
Temperature range -20 °C to 60 °C
Temperature accuracy ± 0.5 °C at 0 °C to 50 °C
Resolution 0.1 °C
Display LED display with white light
Buttons 1 × control knob, 1 × internal calibration and tamper button, 1 × internal reset button
Configuration NFC via mobile app or downlink
Advanced features Child lock, external sensor mode, FUOTA
Power supply 2 × 1.5V Li-FeS2 AA replaceable batteries, 3000 mAh total
Battery life Around 8 years at SF7 EU868, around 5 years at SF10 EU868, 10-minute interval and one control action during a 5-month heating season at 25 °C
Operating temperature -20 °C to +60 °C
Storage temperature -40 °C to +70 °C without batteries
Relative humidity 0% to 95% non-condensing
Ingress protection IP30
Weight 170 g with batteries
Dimensions Ø 52 × 90 mm
Material and color Stainless steel + ABS, white
Installation Latching on the valve
Approvals CE, RoHS
