Product Description
Technical Details
The RAK2270 Sticker Tracker (EU868) is a battery-powered LoRaWAN tracker in a label-like form factor, built to attach directly to products, parcels, and equipment with minimal effort. It’s buttonless by design—peel to activate, stick it on, and start collecting data.
Inside, it’s powered by STM32WLE5 and includes a temperature sensor measuring -20°C to +60°C with 0.1°C resolution, plus an integrated 3-axis accelerometer for motion detection. For real deployments, it also provides up to 64 KB of EEPROM so data like time, temperature, and motion state can be retained locally and forwarded once connectivity is available again.
“Generic” stiocker intended for building custom LoRaWAN solutions and integrating the sticker into your own LNS and software platform.
| Product | RAK2270 Sticker Tracker (Generic) |
|---|---|
| Wireless | LoRaWAN |
| Frequency | EU868 (868 MHz) |
| MCU / Chip | STM32WLE5 |
| Form factor | Label / sticker |
| Activation | Buttonless (sensor activation) |
| Temperature sensor | Built-in |
| Temperature range | -20 °C to +60 °C |
| Temperature resolution | 0.1 °C |
| Accelerometer | Integrated 3-axis motion detection |
| Data storage | EEPROM up to 64 KB |
| Max output power | 22 dBm |
| Antenna gain | 2.0 dBi |
| Battery type | LiMnO2 |
| Battery capacity | 600 mAh |
| Dimensions | 85 × 118 × 1.5 mm |
| Package contents | 1x RAK2270 tracking & temperature sticker, 1x battery |
