Soil pH sensor hub + pH probe LoRaWAN 863–930 MHz – RAKwireless RAK2560 + JXBS-3001-PH-RS

This product bundles the RAK2560 WisNode Sensor Hub (LoRaWAN-only) with the JXBS-3001-PH-RS pH probe for soil pH monitoring. The hub acts as the field datalogger and end device: it collects pH readings from the probe and forwards them over LoRaWAN to your backend for dashboards, analytics, and alerting.

RAK2560 comes in an IP66 waterproof enclosure and provides two sensor probe ports, so you can expand beyond pH when you want a broader site setup. The text also states you can use splitter cables to connect multiple probes / Probe IOs to a single hub port, and extension cables to increase the distance between the hub and the measurement point.

The pH probe is intended for applications where pH drives decisions—especially soil pH measurement for fertility assessment and tuning fertilization and irrigation. Typical deployments include rice fields, greenhouses, vegetable cultivation, orchards/nurseries, flowers, and soil research.

Setup and operation: the hub can be configured via the WisToolBox app (mobile and desktop) and supports automatic detection of power source and sensor probes (stated). Power options listed include 2–4 ER18505 3.6 V 4000 mAh Li-SOCl2 primary batteries (not included) as well as 12 V DC or a solar panel.

Variant note: the lineup also includes a LoRaWAN + NB-IoT version (also available). This SKU is the LoRaWAN-only version for 863–930 MHz operation.
